Merco Tape® M810 Electrical Tape ~ Rubber Self Bonding with Liner for Low Voltage applications
Merco Tape® M810 electrical tape is a 30 mil low voltage self-bonding rubber splicing rubber tape made of high quality, unvulcanized rubber. (Self Bonding: No adhesive or heat etc.,)
Our Merco Tape® M810 is suitable as a primary insulation for splices in electrical wires and cables of not more than 600 volts when used (overwrapped) with a Merco Tape® M807 Friction or Merco Tape® M307 or M801 Vinyl Electrical tapes. It's superior insulating & bonding qualities make it an excellent choice for insulating wire splices, pipe repair, automotive, marine, construction & many other general uses. Imported or US made, as available.
| Specifications and Technical Data Sheet | Material Safety Data Sheet (MSDS, AIS or SDS) |
Available Variations
| Color | Width | Length | Rolls per case |
Tensile lbs/in width |
Adhesion oz/in width |
Thickness mils |
Elongation percent |
Dielectric Strength volts/mil thickness |
Packaging | Country of Origin |
|---|---|---|---|---|---|---|---|---|---|---|
| Black | 18 mm | 22 ft | 100 | 275 | n/a | 30 | 500 | 490 | bulk | USA |
| Black | 36 mm | 22 ft | 24 | 275 | n/a | 30 | 500 | 490 | bulk | USA |
| Black | 48 mm | 22 ft | 50 | 275 | n/a | 30 | 500 | 490 | bulk | USA |
| Black | 3 in | 22 ft | 30 | 275 | n/a | 30 | 500 | 490 | bulk | USA |
